QIAO)) Series Product Comparison
Q5
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
0utput Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-32A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
NO
LCD
Network
Bluetooth/ Wi-Fi
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
lP66
Waterproof
lK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
23*16*7.5cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q6
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
0utput Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
4.3/7inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
YES
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
lP66
Waterproof
lK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q7
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
0utput Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-32A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
NO
LED
3.5 inch
LCD
Network
4G/ Ethernet/ Bluetooth
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
lP66
Waterproof
lK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q8
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
0utput Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug &Charge/ RFID Card/APP/ Bluetooth
Startup Method
YES
LED
4.3 inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
lP66
Waterproof
lK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
FAQs
No. The E501S starts charging automatically when connected to a vehicle that is ready to charge. Current adjustment, start delay and charging stop are controlled directly on the unit.
Yes. Use the T touch control on the charger to delay the start of charging. Follow the user manual for the available settings and operating steps.
Yes. Use the A touch control to select a lower current. The minimum is 6 A, while the maximum is 16 A for the 11 kW version and 32 A for the 7 kW and 22 kW versions. Keep the setting within the limit approved for your installation.
Use the S touch control and confirm that charging has stopped. Unlock the connector through your vehicle if required, then disconnect it.
No. Reaching 22 kW requires a compatible three-phase supply and a vehicle that supports 22 kW AC charging. A vehicle with a lower AC charging limit will charge at a lower power.
