Deep Dive
QIAO)) Series Product Comparison
Q5
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
NO
LCD
Network
Bluetooth/ Wi-Fi
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
23*16*7.5cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q6
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
4.3/7inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
YES
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q7
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-32A
Current
Plug &Charge/ RFID Card/
APP/ Bluetooth
Startup Method
NO
LED
3.5 inch
LCD
Network
Bluetooth/ Wi-Fi
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q8
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ RFID Card/APP/ Bluetooth
Startup Method
YES
LED
4.3 inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
FAQs
Both versions provide automatic charging with LED status indication. The E801N adds A/T/S touch controls for adjusting current, delaying the start and stopping charging directly at the unit.
No. Automatic charging and the A/T/S controls work without an app, internet connection or RFID card.
The supported range is 6–32 A for the 7 kW and 22 kW versions, and 6–16 A for the 11 kW version. Follow the user manual for the available settings and keep the selection within your installation’s approved limit.
Yes. Use the T control to set a start delay directly at the charger. Follow the supplied instructions to select and activate the delay.
Use the S control to stop the session. Once charging has stopped, unlock the vehicle connector if needed and disconnect it. The separate side button provides emergency stop and reset functions.
Yes. The standard attached Type 2 cable is 5 m long. Contact us before ordering to discuss a custom length.
