Deep Dive
QIAO)) Series Product Comparison
Q5
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
NO
LCD
Network
Bluetooth/ Wi-Fi
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
23*16*7.5cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q6
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ Fingerprint/ Password/ RFID Card/ APP/ Bluetooth
Startup Method
YES
LED
4.3/7inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
YES
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q7
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-32A
Current
Plug &Charge/ RFID Card/
APP/ Bluetooth
Startup Method
NO
LED
3.5 inch
LCD
Network
Bluetooth/ Wi-Fi
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
Q8
All EVs
EVs Compatibility
7kw/ 11kw/ 22kw
Output Power
Single-phase:120-240V Three-phase:380-400V
Voltage
16-48A
Current
Plug & Charge/ RFID Card/APP/ Bluetooth
Startup Method
YES
LED
4.3 inch
LCD
Network
4G/ Ethernet/ Wifi/ Bluetooth
NO
DLB
TypeA/ TypeA+6/ CCID20
Leakage Protection
14 Protections
Electrical Protection
F1
Weather Resistance
IP66
Waterproof
IK10
Fall Protection
-40°C~80°C
Storage Temperature
-30'C~50'C
Operating Temperature
5%~95%
Operating Humidity
<2000M
Altitude
Wall Mount / Pole Mount
Installation Type
≥10 years
Design Life
24 Months
Warranty Period
30*18*12cm
Product size
5M/7.62M/ customized
Cable Length
98%
Charging Efficiency
FAQs
Yes. An attached 5 m Type 2 cable is included as standard. Custom lengths are available on request. Contact us before ordering to discuss the length you need.
No. Reaching 22 kW requires a suitable three-phase supply and a vehicle that supports 22 kW AC charging. A vehicle with a lower AC charging limit will charge at a lower power.
On CEE plug versions, the sensor monitors plug temperature. If the plug becomes too hot, the charger automatically reduces charging current to help bring the temperature down. A suitable socket and correctly installed circuit are still required.
Yes. The charger has IP66 protection, IK10 impact resistance and an operating temperature range of −30°C to +62°C. Follow the installation instructions and store the connector in its holster when not in use.
Stop charging through your vehicle’s charging controls. Once charging has stopped, unlock and disconnect the connector. Use the side emergency stop/reset button according to the user manual.
